SMILE — SIM Mobile Identity for Ledgers

Turn your SIM card into a x402 crypto wallet. No applets. No passwords. No KYC.

SMILE is a breakthrough protocol that derives x402 wallets directly from SIM cards, using open standards, 2G-5G telecom APIs, and the trusted cryptography already built into mobile networks.

Every SIM card already belongs to the world’s largest identity network. SMILE turns it into the world’s most universal x402 wallet.

With SMILE, your SIM card instantly becomes a secure, self-sovereign x402 identity — seamlessly integrated with the x402 protocol to enable trustless transactions, instant onboarding, and hardware-grade wallet security.

Your phone number is now your x402 wallet.

---

🚀 What SMILE Does

• 🧬 Derives a BIP-32/39 HD wallet from the SIM’s AKA authentication keys
• 🛰 Uses only existing 3G/4G/5G SIM commands — no Java Card or carrier mods
• 🔏 HKDF → BIP seed → master key — all on device, zero exposure of Ki or K

---

💡 Why It Matters

• No fragile seed UX — the SIM is your root of trust
• Pay-per-use connectivity: pay per MB, per minute, per sensor tick
• Tap-to-transact IoT: vending machines, EV chargers, drones, kiosks
• Carrier ↔ crypto flywheel: airtime, rewards, promos → on-chain assets
• Signed operations: firmware updates, door unlocks, telemetry notarization

---

Table of Contents

• What SMILE Does
• Why It Matters
• Build and Run SMILE
• Using SmileSeedDerivation Class
  • Overview
  • Public Interface Summary
  • deriveBIP32MasterSeed2G
  • deriveBIP32MasterSeed3G
  • deriveBIP32MasterSeed4G
  • deriveBIP32MasterSeed5G
  • References
• Using Bip32Wallet Class
  • deriveWalletPrivateKey
  • computePublicKeyFromPrivate
• Mathematical Spec: SMILE BIP32 Master Seed Derivation
  • 1. Overview
  • 2. Notation
  • 3. Cryptographic Framework
    • 3.1. HKDF (RFC 5869)
  • 4. deriveBIP32MasterSeed2G
  • 5. deriveBIP32MasterSeed3G
  • 6. deriveBIP32MasterSeed4G
  • 7. deriveBIP32MasterSeed5G
  • 8. Security Discussion
  • 9. Example End-to-End Derivation Flow (5G)
  • 10. Implementation Notes
  • 11. Security Level Summary

---

🚀 Build and Run SMILE

1. Clone the repository

git clone https://github.com/skalenetwork/smile --recursive

2. Bootstrap and install dependencies using vcpkg

./external/vcpkg/bootstrap-vcpkg.sh
./external/vcpkg/vcpkg install

3. Configure and build with CMake

cmake -S . -B build   -DCMAKE_BUILD_TYPE=Release   -DCMAKE_TOOLCHAIN_FILE=external/vcpkg/scripts/buildsystems/vcpkg.cmake   -DVCPKG_FEATURE_FLAGS=manifests   -DVCPKG_TARGET_TRIPLET=x64-linux

cmake --build build -j

4. Run the SMILE demo

build/smile

---

🧠 Notes

• ✅ Tested on: Ubuntu 22.04 and later
• 🧩 Coming soon: Windows and macOS builds

---

Using SmileSeedDerivation Class

Usage: #include SmileSeedDerivation.h

Overview

SmileSeedDerivation provides a unified cryptographic abstraction for deriving 32-byte deterministic master seeds (e.g., for BIP-32 hierarchical key systems) directly from cellular authentication primitives across multiple generations — 2G (GSM), 3G (UMTS-AKA), 4G (EPS-AKA), and 5G (5G-AKA).

Each generation uses the same conceptual structure:

Generation	Underlying Standard	Key Algorithm	Output
2G	GSM / TS 51.011	COMP128-1 (A3/A8) → SHA-256	32-byte seed
3G	TS 33.102 / TS 35.206	Milenage → SHA-256	32-byte seed
4G	TS 33.401	EPS-AKA KDF → SHA-256	32-byte seed
5G	TS 33.501	5G-AKA KDF → HKDF-SHA-256	32-byte seed

---

Public Interface Summary

Function	Input	Core Algorithm	Output
deriveBIP32MasterSeed2G	RAND, Ki	COMP128-1 → HKDF-SHA-256(SRES ‖ Kc)	32-byte seed
deriveBIP32MasterSeed3G	RAND, AUTN, K, OPc, AMF	Milenage → HKDF-SHA-256(RES ‖ CK ‖ IK)	32-byte seed
deriveBIP32MasterSeed4G	RAND, AUTN, K, OPc, AMF, SNN	EPS-AKA KDF → HKDF-SHA-256(RES ‖ K_ASME)	32-byte seed
deriveBIP32MasterSeed5G	RAND, AUTN, K, OPc, AMF, SNN	5G-AKA KDF → HKDF-SHA-256(K_SEAF)	32-byte seed

---

deriveBIP32MasterSeed2G

static array32 deriveBIP32MasterSeed2G(const array16 &rand, const array16 &ki);

Description

Derives a 32-byte BIP-32 master seed from GSM (2G) authentication results.

Parameters

Name	Size	Description
rand	16 bytes	Network random challenge (RAND)
ki	16 bytes	Subscriber secret key stored on the SIM card (Ki)

Returns

• 32-byte seed. Throws exception on failure.

Notes

• COMP128-1 used internally as demonstration; real SIMs may use proprietary A3/A8 variants.

---

deriveBIP32MasterSeed3G

static array32 deriveBIP32MasterSeed3G(
    const array16 &rand,
    const array16 &autn,
    const array16 &k,
    const array16 &opc,
    const array2 &amf);

Description

Implements 3G/UMTS-AKA (Authentication and Key Agreement), and derives a 32-byte BIP-32 master seed from the authentication results (RES, CK, IK).

Parameters

Name	Size	Description
rand	16 B	Network challenge RAND
autn	16 B	AUTN = (SQN ⊕ AK) ‖ AMF ‖ MAC-A
k	16 B	Subscriber long-term key K
opc	16 B	Operator variant constant OPc = OP ⊕ AES_K(OP). Fixed per operator.
amf	2 B	Authentication Management Field (typically 0x8000). Fixed per operator.

Returns

• 32-byte seed. Throws exception on failure.

Standards

• 3GPP TS 33.102 § 6.3
• 3GPP TS 35.205 – 35.207 (Milenage)

---

deriveBIP32MasterSeed4G

static array32 deriveBIP32MasterSeed4G(
    const array16 &rand,
    const array16 &autn,
    const array16 &k,
    const array16 &opc,
    const array2 &amf,
    const std::string &snn);

Description

Derives a 32-byte BIP-32 master seed from LTE/EPS-AKA authentication results (RES, K_ASME).

Parameters

Name	Description
rand	16-byte network challenge RAND
autn	16-byte authentication token AUTN
k	Subscriber key K
opc	Operator constant OPc. Fixed per operator.
amf	2-byte Authentication Management Field. Fixed per operator.
snn	Serving Network Name (e.g., "mnc410.mcc310.3gppnetwork.org"). Fixed per operator.

Returns

• 32-byte seed. Throws exception on failure.

Standards

• 3GPP TS 33.401 Annex A.2–A.4
• 3GPP TS 23.003 § 28.7 (SNN format)

---

deriveBIP32MasterSeed5G

static array32 deriveBIP32MasterSeed5G(
    const array16 &rand,
    const array16 &autn,
    const array16 &k,
    const array16 &opc,
    const array2 &amf,
    const std::string &snn);

Description

Computes a 32-byte BIP-32 master seed from 5G-AKA authentication results (RES*, K_SEAF).

Parameters

Name	Description
rand	16-byte RAND
autn	16-byte AUTN
k	16-byte subscriber key
opc	16-byte operator variant constant. Fixed per operator
amf	2-byte AMF. Fixed per operator.
snn	Serving Network Name (as per 3GPP TS 33.501). Fixed per operator

Returns

• 32-byte seed. Throws exception on failure.

Standards

• 3GPP TS 33.501 Annex A.4–A.6
• RFC 5869 (HKDF)
• 3GPP TS 24.501 (SNN naming)

---

References

Standard	Document	Description
GSM / 2G	3GPP TS 51.011	SIM–ME interface, A3/A8
3G	3GPP TS 33.102 / 35.205-207	UMTS AKA / Milenage
4G	3GPP TS 33.401	EPS AKA KDF for K_ASME
5G	3GPP TS 33.501	5G-AKA KDF for K_SEAF, RES*
KDF	RFC 5869	HMAC-based Key Derivation Function

---

Using Bip32Wallet Class

Header: #include "Bip32Wallet.h"

Overview

Bip32Wallet provides a lightweight, standards-compliant implementation of the BIP32 hierarchical deterministic (HD) wallet key derivation process.

It exposes stateless cryptographic helpers for deriving:

• child private keys (both hardened and non-hardened) from any seed, and
• the corresponding compressed public key on the secp256k1 elliptic curve.

---

Public Interface Summary

Function	Input	Output	Description
deriveWalletPrivateKey	seed (32 B), index (uint32)	child private key (32 B)	Derives a child private key from a BIP32 seed
computePublicKeyFromPrivate	private key (32 B)	compressed pubkey (33 B)	Computes compressed secp256k1 public key

---

deriveWalletPrivateKey

static array32 deriveWalletPrivateKey(const array32& seed, uint32_t index = 0);

Description

Derives a child private key from a given 32-byte BIP32 seed, following the standard BIP32 key derivation procedure.

Parameters

Name	Type	Description
seed	array32	32-byte BIP32 master seed
index	uint32_t	Child index; bit 31 (0x80000000) selects hardened derivation. Default = 0

Returns

• 32-byte derived child private key (array32). Throws exception on failure.

---

computePublicKeyFromPrivate

static std::array<uint8_t, 33> computePublicKeyFromPrivate(const array32 &privkey);

Description

Computes a compressed public key (33 bytes) from a given private key.

Parameters

Name	Type	Description
privkey	array32	32-byte secp256k1 private key

Returns

• 33-byte compressed public key. Throws exception on failure.

---

Cryptographic Notes

• Curve parameters follow secp256k1 (Bitcoin, Ethereum, SKALE, etc.).

---

Standards & References

Specification	Section	Description
BIP32	§4–§5	Hierarchical Deterministic Wallets
SECP256K1	§2.7	Elliptic Curve Parameters
RFC 2104	—	HMAC Construction
OpenSSL EVP / EC API	—	Cryptographic primitives

Mathematical Spec: SMILE BIP32 Master Seed Derivation

Standards:

• 3GPP TS 33.102 (3G Security Architecture)
• 3GPP TS 33.401 (LTE Security Architecture)
• 3GPP TS 33.501 (5G Security Architecture)
• RFC 5869: HMAC-based Key Derivation Function (HKDF)
• BIP32: Hierarchical Deterministic Wallets

---

1. Overview

This specification defines a set of deterministic algorithms for deriving a BIP32 master seed using SIM/USIM/ISIM-based authentication primitives from mobile communication systems (2G–5G).

The approach leverages cryptographically secure values generated during cellular authentication — such as SRES, Kc, CK, IK, K_ASME, and K_SEAF — as entropy sources for the BIP32 root seed.

The final seed derivation uses the standardized HKDF function (RFC 5869) over the authentication-derived keying material.

---

2. Notation

Symbol	Meaning
RAND	Random challenge generated by the network
AUTN	Authentication token
K	Subscriber permanent key (stored securely in SIM/USIM/ISIM)
OPc	Operator variant key constant (Milenage parameter)
AMF	Authentication Management Field
SNN	Serving Network Name
SRES	Signed response (2G AKA output)
Kc	Cipher key (2G AKA output)
CK	Cipher key (3G/4G/5G AKA output)
IK	Integrity key (3G/4G/5G AKA output)
AK	Anonymity key (3G/4G/5G AKA output)
K_ASME	Access Security Management Entity key (4G)
K_SEAF	Security Anchor Function key (5G)
HMAC_SHA256(key, data)	HMAC using SHA-256
HKDF_Extract(salt, IKM)	RFC 5869 extract stage
HKDF_Expand(PRK, info, L)	RFC 5869 expand stage
‖	Byte concatenation

---

3. Cryptographic Framework

3.1. HKDF (RFC 5869)

RFC 5869 defines the HMAC-based Key Derivation Function (HKDF), a simple and secure method for deriving strong cryptographic keys from initial keying material using HMAC. It standardizes a two-step process—extract and expand—to ensure key separation, uniformity, and resistance to entropy loss or bias in the input material.

Let:

• IKM be the input keying material (entropy source)
• salt be an optional context string (domain separation)
• info be an optional identifier for derived key usage
• L be the desired output length (32 bytes)

Then:

PRK = HMAC_SHA256(salt, IKM)
OKM = HMAC_SHA256(PRK, info || 0x01)
Seed = OKM[0..31]

---

4. deriveBIP32MasterSeed2G

4.1. Authentication Source

2G authentication (GSM AKA) yields:

(SRES, Kc) = A3/A8(K, RAND)

• SRES: 32-bit signed response
• Kc: 64-bit session key

4.2. Input Keying Material (IKM)

IKM_2G = SRES || Kc

(12 bytes total)

4.3. HKDF Context

• Salt = "SMILE|2G|salt|v1"
• Info = "SMILE|2G|seed|v1"

4.4. Derivation Equation

Seed_2G = HKDF_SHA256(IKM_2G, Salt, Info)

4.5. Output

• 32-byte (32-byte) seed suitable as BIP32 master seed.
• Entropy source limited (~96 bits), so use only for deterministic derivations, not high-assurance wallet seeds.

---

5. deriveBIP32MasterSeed3G

5.1. Authentication Source

3G AKA (Milenage) yields:

(RES, CK, IK, AK) = f1..5(K, RAND, OPc, AMF)

• CK: 128-bit cipher key
• IK: 128-bit integrity key

5.2. Input Keying Material

IKM_3G = CK || IK

(256 bits)

5.3. Salt Construction

ctx = RAND || AUTN || "SMILE|3G|salt|v1"
Salt_3G = SHA256(ctx)

5.4. HKDF Derivation

Seed_3G = HKDF_SHA256(IKM_3G, Salt_3G, "SMILE|3G|seed|v1")

5.5. Output

• 32-byte BIP32 seed with high entropy (~256 bits).
• Combines network challenge RAND with key material for domain separation.

---

6. deriveBIP32MasterSeed4G

6.1. Authentication Source

LTE AKA yields the derived Access Security Management Entity key K_ASME from CK and IK using:

K_ASME = HMAC_SHA256(CK||IK, FC||SNN||L0||(SQN⊕AK)||L1)

(Per 3GPP TS 33.401 §A.2.1, with FC = 0x10.)

6.2. Input Keying Material

IKM_4G = K_ASME

(256 bits)

6.3. Salt Construction

ctx = SNN || "|" || "SMILE|4G|salt|v1"
Salt_4G = SHA256(ctx)

6.4. HKDF Derivation

Seed_4G = HKDF_SHA256(IKM_4G, Salt_4G, "SMILE|4G|seed|v1")

6.5. Output

• 32-byte BIP32 seed.
• Strong cryptographic entropy, sourced from LTE authentication hierarchy.
• Safe for generating HD wallet roots tied to mobile identity.

---

7. deriveBIP32MasterSeed5G

7.1. Authentication Source

5G AKA (TS 33.501) derives the following hierarchy:

K_AUSF = HMAC_SHA256(CK||IK, FC||SNN||L0||(SQN⊕AK)||L1), FC = 0x6A
K_SEAF = HMAC_SHA256(K_AUSF, FC||SNN||L0), FC = 0x6B

7.2. Input Keying Material

IKM_5G = K_SEAF

7.3. Salt Construction

ctx = SNN || "|" || "SMILE|5G|salt|v1"
Salt_5G = SHA256(ctx)

7.4. HKDF Derivation

Seed_5G = HKDF_SHA256(IKM_5G, Salt_5G, "SMILE|5G|seed|v1")

7.5. Output

• 32-byte master seed (BIP32 m/ root).
• Entropy sourced from 5G key hierarchy (K_SEAF), which derives from K via CK/IK → K_AUSF → K_SEAF.
• Represents cryptographic coupling between SIM identity and HD wallet seed.

---

8. Security Discussion

1. Entropy:

   • 2G: ≤ 96 bits
   • 3G/4G/5G: ≥ 256 bits (AES-based + random challenge)

2. Forward Secrecy:

   • Each derivation depends on network RAND, ensuring session uniqueness.

3. Domain Separation:

   • HKDF salt and info labels include generation and versioning tags (SMILE|xG|...|v1).

4. Compatibility:

   • Final output format (32 bytes) matches BIP32 master seed input for:

     (m, c) = HMAC_SHA512("Bitcoin seed", Seed)


---

9. Example End-to-End Derivation Flow (5G)

Step 1: AKA → CK, IK, AK, RES
Step 2: K_AUSF = HMAC_SHA256(CK||IK, 0x6A||SNN||L0||(SQN⊕AK)||L1)
Step 3: K_SEAF = HMAC_SHA256(K_AUSF, 0x6B||SNN||L0)
Step 4: Salt = SHA256(SNN||"|"||"SMILE|5G|salt|v1")
Step 5: Seed = HKDF_SHA256(K_SEAF, Salt, "SMILE|5G|seed|v1")
Output: Seed_5G ∈ {0,1}^256

---

10. Implementation Notes

• All HKDF operations use HMAC-SHA256 as the PRF.
• All salts and info strings are ASCII-encoded.
• The seed output can be directly passed to BIP32 as the entropy input for HMAC-SHA512 keychain derivation.

---

11. Security Level Summary

Generation	Entropy Source	Algorithmic Base	Cryptographic Strength
2G	(SRES‖Kc)	COMP128 / A3/A8	Weak / Legacy
3G	(CK‖IK) via Milenage	AES-128	Strong
4G	K_ASME (HMAC-SHA256)	AES-128 + SHA256	Strong
5G	K_SEAF (HMAC-SHA256 chain)	AES-128 + SHA256	Very Strong
